Silicon Steel Slitting Line
Detail Information
Silicon Steel Slitting Line
Model: HL-ZJ1250-60,HL-ZJ1250-90
HL-ZJ1250-60,HL-ZJ1250-900.5mm71mm
The equipment is used for slit the silicon steel, tinplate, steel, aluminum and etc. It used Siemens PLC, Yuken hydraulic components and NSK bearings in the key position.
Technical Specifications
| Name & Model | HL-ZJ1250-90A slitting line |
| Use | For accurately slitting silicon-steel, strip steel and aluminum strip. |
| Characteristics | German Siemens PLC control, Japanese YUKEN brand hydraulic components, Carbide knives. |
| Technical parameters | 1）Slitting thickness：0.2-0.5mm |
| 2）Max slitting width：1250mm | |
| 3）Max uncoiling weight：10T | |
| 4）Uncoiling O.D.：1400mm | |
| 5）Uncoiling I.D.：385-450mm / 480-520mm | |
| 6）Slitter mandrel diameter：120mm | |
| 7）Slitting quantity：15 strips | |
| 8）Slitting width：≥71mm | |
| 9）Recoiling weight：≤10T | |
| 10）Recoiling I.D.：508mm | |
| 11) Slitting parallel tolerance：0.05mm/m | |
| 12）Burr：≤0.02mm | |
| 13）Slitting width tolerance：0.05mm | |
| 14）Speed regulation method：DC, frequency control | |
| 15）Speed：10-90m/min | |
| 16）Total consumption：90Kw | |
| 17）Land occupation：16×7m | |
| 18）Other performance：All hydraulic driven, Proper circle recoiling, Pneumatic-expansion type strip tightener, With high-precision knife grinder, Side collector. | |
| 19）Unique design：Touch screen operation, Siemens PLC control, Whole ling automatic running, On-line adjust slitting width, Adjust knife without removing shaft, On-line grinding. |
Product Gallery
Silicon Steel Slitting Line — View 1
Silicon Steel Slitting Line — View 2
Silicon Steel Slitting Line — View 3
Silicon Steel Slitting Line — View 4
Silicon Steel Slitting Line — View 5
Silicon Steel Slitting Line — View 6
